D ata Sheet
AH534A_W
Part Number : SPHWHTA5N000W2RSEC

SPHWHTA5N000W2RSEC

Introduction

Part number : SPHWHTA5N000W2RSEC
Automotive head lamp lighting source

Features
ðŸ
ðŸ
ðŸ
ðŸ
ðŸ
ðŸ

Package : Silicone covered ceramic substrate
Dimension : 5.3 mm x 3.3 mm
Luminous flux : Typ. 700 lm @700 mA
Color coordinate group : Appropriate to ECE
Chip configuration : 4 chip array (1x4)
Viewing angle: 120Ú

Applications
ðŸ Automotive head lamp

Environmental compliance
Samsung is compliant to the restrictions of hazardous substances in electronic equipment, namely, the RoHS, ELV, ISO14001 and REACH directives.
Samsung will not intentionally supplement the restricted materials to the head lamp LED product : Cd, Pb, Hg, PBBs, PBDEs and Cr6+

2014/11/05/Rev.03

- 1 -

SPHWHTA5N000W2RSEC

Table of contents
ðŸ

Product overview

ðŸ

Part number description
