Quick Reference

Hybrid Camera Solutions
IPELA HYBRIDTM­ Sony's IP and Analogue over Coax Technology* ­ Offers Cost-effective and Environmentally-friendly Retrofit Solutions for Existing Analogue CCTV Systems
Sony offers a new video surveillance technology providing simultaneous transmission of IP and analogue signals over a conventional coaxial video cable. This provides an easy migration path from analogue to IP , utilizing existing infrastructure to keep cost to a minimum. The Sony IPELA HYBRID solution comprises a range of hybrid cameras that connect via coax cable to a 4-channel receiver. These unique solutions deliver the following advantages: Cost-effective and environmentally-friendly surveillance systems that can be easily migrated from an analogue CCTV system to an IP network-based system, making the most of any existing surveillance infrastructure (eg, coaxial cables, local power supplies, matrix switchers, controllers, and video wall monitors) Simultaneous use of IP HD video and analogue SD video Utilization of the advanced features and functionalities offered by IP network cameras Extended cable length of up to 300 m (1,000 feet)** Minimized latency of analogue video for live monitoring The Sony IPELA HYBRID solution is ideally suited to a broad range of applications in locations where extensive analogue infrastructure is already in place, and where long cable runs are required, such as commercial buildings, transport facilities, government buildings, education and casinos.
* Sony's IP and analogue over coax technology is developed based on Intersil Corporation's SLOCTM (Security Link Over Coax) technology. ** Max cable length depends on cable grade and condition.

Simple Migration from Analogue to IP
Before

Analogue

IP

Digital Video Recorder

Monitor

Analogue Cameras

Network Video Recorder
(with Video Management Software)

After

Monitor

Hybrid Receiver Hybrid Cameras

Network Client PC

Hybrid Migration
Before

Analogue

IP

Hybrid Camera Solution from Sony

Analogue SD Video Low Latency Monitoring Matrix Switcher

Monitors

Controller

Digital Video Recorder Analogue Cameras

Analogue SD Signal
Video Wall & Matrix Switcher Matrix Switcher Monitors Controller
