SNC-DH140T

Network HD Camera--V series

Vandal-Resistant 720p HD Security Camera with View-DR Technology
Excellent 720p HD picture quality, supporting H.264 at 30 fps 1.3 Megapixel (1280 x 1024) Three codecs (H.264, MPEG-4, JPEG) and a dual streaming capability The "Exmor" CMOS sensor incorporated to realize high image quality and low noise

Key Features
· View-DR--Sony's innovative Wide Dynamic Range technology-- to capture objects clearly and adaptively even under very harsh severe backlight or highlight conditions.
· Optical Day/Night function to switch to Day or Night mode depending on the light level. · XDNR (eXcellent Dynamic Noise Reduction) technology for clear images without motion blur under low illumination.

OFF OFF

ON

Actual Images

ON

Actual Images

· Powered by either AC 24 V, DC 12 V, or PoE (Power over Eithernet) for easy installation. · Equipped with a BNC connector and a phono jack to instantly monitor the video while installing the camera. · ONVIF (Open Network Video Interface Forum) conformance that ensures greater interoperability and more flexibility in building multiple-vendor systems.

· Visibility Enhancer to optimize the brightness and color reproduction of an image dynamically on a pixel-by-pixel basis while continuously adapting to the scene, within the given dynamic range. · IK10-rated vandal-resistant feature to protect the camera from destructive behaviors. · Easy Focus/Easy Zoom functions for easy installation. · DEPA Advanced Intelligent Video and Audio Analytics to trigger an alarm, based on user-defined rules.

SPECIFICATIONS
SNC-DH140T
Camera Image device Minimum illumination Number of effective pixels (H x V) Electronic shutter speed

SYSTEM CONFIGURATION
HD monitor

Gain control Exposure control White balance mode Lens type Zoom ratio Horizontal viewing angle Focal length F-number Minimum objects distance Powered focus Powered zoom Camera Features Day/Night *3 Wide-D Image enhancement Noise reduction Image Codec image size (H × V) Video compression format Codec streaming capability Maximum frame rate

1/3 type progressive scan "Exmor" CMOS sensor Color : 0.20 lx, B/W : 0.10 lx (F1.2/View-DR OFF/XDNR ON-Middle/VE OFF/AGC High/50 IRE[IP]) 1.4 Megapixel (1329 x 1049) 1s to 1/10000s Auto (3 levels) Auto, EV Compensation*1, Auto Slow Shutter*2 Auto (ATW, ATW-Pro), Preset, One-push WB, Manual Vari-focal lens Optical 2.9X (x2 Digital Zoom) 85.4 to 31.2 degrees f=3.1 to 8.9 mm F1.2 (Wide), F2.1 (Tele) 300 mm Yes (Easy Focus) Yes (Easy Zoom) Yes View-DR (125 dB: Theoretical) Visibility Enhancer XDNR 1280 x 1024, 1280 x 960, 1280 x 800, 1280 x 720, 1024 x 768, 1024 x 576, 800 x 480, 768 x 576, 720 x 576, 720 x 480, 704 x 576, 640 x 480, 640 x 368, 384 x 288, 320 x 240, 320 x 192 (H.264, MPEG-4, JPEG) H.264, MPEG-4, JPEG Dual streaming H.264: 20fps (1280 x 1024) / 30 fps (1280 x 720) MPEG-4: 25fps (1280 x 1024) / 30 fps (1280 x 720) JPEG: 30fps (1280 x 1024) / 30 fps (1280 x 720) G.711/G.726 Yes (with built-in Post Filter) No Yes IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) Yes No 10 IEEE802.1X NTSC / PAL 600 TV lines More than 50 dB 10BASE-T / 100BASE-TX (RJ-45) No No BNC x 1 Phono jack x 1 x1 x2 Mini-jack (monaural), MIC IN/LINE IN: 2.5 V DC plug-in power Mini-jack (monaural), Max output level: 1 Vrms 980g (2 lb 3 oz) ø140 x 119 mm (5 5/8 x 4 3/4 inches) PoE, AC 24 V, DC 12 V 8.0 W max. 0 to 50 °C (32 to 122°F) -10 to +50 °C (23 to 122°F) -20 to +60 °C (-4 to 140 °F) IK10 UL2044, FCC 15B Class A, IC Class A, IEC60950-1, EN55022(A)+EN55024+EN50130-4, VCCI Class A, C-Tick Class A Windows XP, Windows Vista, Windows 7 Intel Core2 Duo 2 GHz or higher 1 GB or more Microsoft Internet Explorer Ver6.0, 7.0, or 8.0 CD-ROM (User's guides, SNC Toolbox), Installation manual, Template, Wire rope, Bracket, LAN cable, BNC cable, Power input cable, I/O cable, Audio Cable, Warranty booklet, M4 shoulder screw, M4 screws (2), Wrench

SNC-DH140T

Recording Server NSR-1000 Series Recording Software IMZ-NS100 Series

Network

SNC-DH140T

PC

DIMENSIONS
ø140 (5 5/8)

Unit: mm (inches)
