65" LCD Semi-Outdoor Public Display
GXD-L65H1 Public Displays

Key Features
IP54 Dust-proof & Splash-proof design
Water splashing on the screen from any angle will not affect the display.The design prevents dust particles entering in sufficient quantity and size to interfere with the safe and proper operation of the equipment.

The GXD-L65H1 LCD public display has been designed to create an impact. With a 65" screen size and full HD resolution, this public display is able to convey your message vibrantly in semi-outdoor environments. Robustly built, it is both dust-proof, splash-proof and has an impact resistant tempered glass front panel. In addition, the GXD-L65H1 public display has been designed for reliability. This display incorporates an innovative `Intelligent Backlight Control System' which ensures the screen will continue working even if one or more of the backlight lamps fails. The robustness and the reliability of this screen make it perfectly suited for installation into transport, manufacturing, sporting venues and retail environments. Furthermore, the HDSDI compatibility makes it suitable for broadcast and healthcare applications.

Intelligent Backlight Control System
If one of the Cold Cathode Fluorescent Lamps (CCFL) which make up the backlight fails, the display will still work. If a second CCL fails, a warning report will be sent.

1080 Full HD 1080 Full High Definition refers to 1080 lines. This is the common broadcast format and 1080 Full HD replicates this exactly.

Picture-in-Picture (PiP), Pictureand-Picture (PaP) PIP allows for the picture from a secondary source to be displayed within the main picture. PAP allows the pictures from 2 separate sources to be displayed side-by-side.

Other Features
­ Anti-glare (AG) and Anti-Reflection (AR) Coated Front Glass Panel - to promote maximum visibility ­ High Level of Brightness (LCD Panel) - 700 cd/m2 ­ Landscape & Portrait Installation ­ Sony logo and Menu are automatically switched according to screen layout ­ Multi Display Setup - Besides 2x2, 3x3 and 4x4, you can now choose 1x2, 1x3, 1x4, 2x1, 3x1 and 4x1 formations

High Contrast Ratio of 2500:1 The high contrast ratio of this display allows a distinct differentiation between the darkest and brightest colour thereby optimising the clarity of your message.

Range of Connectivity Options
This display comes with an array of connectivity options: It includes a built-in RJ45 network connection and is HDSDI Compatible. High Definition connectivity options include HDMI, DVI­ HDCP and inputs.

Impact resistant Front Panel
The robust glass front provides protection against impact, dirt and splashing.

GXD-L65H1 Specifications
Panel Panel system Panel size Native resolution Maximum resolution Luminance Contrast (dark room) Viewing angle (H/V) Pixel size (HxV) Colours Display area (HxV) Input connectors PC Video Audio Control Output connectors PC Video Audio Speaker L/R Video signal Colour system Sampling Rate Power requirements Requirements Consumption Standby Dimensions Dimensions Shipping Dimensions (Kg/lb) Shipping Weight Optional slots Optional slots PIP/PAP PIP/PAP Multi-display setup Multi-display setup Bezel colours Colours available Operating conditions Temperature Humidity Supplied accessories AC Power Cord x1, Remote Control RM-FW002 x1, Size AA [R6] Batteries x2, AC Plug Holder x2, LAN Cable x1, Operating Instructions x1, Installation Manual for Dealers x 1 Optional accessories Speakers SS-SPG02 -10°C ~ 40°C (14°F ~ 104°F) 20% ~ 90% (no condensation) Silver Dimensions 2x2 / 3x3 / 4x4, 1x2 / 1x3 / 1x4, 2x1 / 3x1 / 4x1 Yes / Yes 1 (Video/Com Port) 1557x931x183mm 1681 x 1085 x 448 (w x h xd) 94 / 207.2 Approximately 103kg AC100-240V, 50/60Hz, Max 5.5A 540W (max.) 1W (Network not supported) NTSC, PAL, NTSC4.43, PAL-M, PAL60, PAL-N 13.5MHz to 162MHz RGB / Component Video (HD15) Composite Video (BNC) (Stereo mini jack) x1 Speaker Output (L/R) 6ohms 7W+7W HD15/DVI-HDCP Composite Video (BNC) / S-Video (mini-DIN4) / Component Video (HD15) / HDMI (Stereo mini jack) x3 LAN (RJ45) / RS232C* / S Control*
* via option board BKM-FW21

www.sonybiz.net/publicdisplays
Option Board

LCD Panel 65" 1920x1080 1920x1200 700 cd/m2 2500:1 178º/178º 0.744x0.744mm 1.06 billions 1428.48x803.52mm

BKM-FW50 Digital Signage Board BKM-FW21 Monitor Control Adaptor (RS232C straight cable) (Control S In/Out) BKM-FW16 HDSDI Input/Output Adaptor (with audio) BKM-FW15 HDMI Input Adaptor (x2 inputs) BKM-FW12 Component/RGB Active Through Board BKM-FW11 Component/RGB Adaptor BKM-FW10 Video Input/Output Board Safety regulations

Yes Yes

Yes Yes No [Built-in] Yes No [Built-in]

UL 60950-1, CSA No. 60950-1-03 (c-UL), FCC Class B, IC Class B, EN 60950-1 (NEMKO), CE, C-Tick

Accessories · KM-FW50DigitalSignageBoardfordisplayofimagesandvideoclips.Enablesdownloadof B content via an IP connection and control via a web browser. · KM-FW21MonitorControlAdaptor(straightcable). B · KM-FW16HDSDIInput/OutputAdaptor(withaudio). B · KM-FW15HDMIInputAdaptor(x2inputs). B · KM-FW11Component/RGBInputAdaptorwithBNCx5connectors B

BKM-FW50
