3LCD installation projector with 5200 ANSI lumens
VPL-FX41(L) Installation Projector

Key Features
The VPL-FX41 is the newest addition to the F-series range of projectors. Like its counterparts, (the VPL-FE40 and VPL-FX40), it features an ultra modern sleek design and Sony's innovative BrightEraTM technology. The VPL-FX41 delivers an impressive 5200 ANSI lumens compared to the 4000 ANSI lumens of the VPL-FX40. It is capable of projecting bright and clear pictures ­ even in high ambient lighting environments. This makes it ideal to deliver high-impact multimedia presentations in locations such as boardrooms, large conference rooms, R&D facilities and university classrooms.
5200

3LCD BrightEra technology
This innovative inorganic panel technology was designed by Sony to deliver improved panel light resistance, higher brightness, higher resolution and increased panel reliability.

Brightness
By combining the new BrightEraTM inorganic LCD panels with a costefficient 275W ultra high pressure lamp, this projector achieves outstanding brightness of 5200 ANSI lumens.

With outstanding functionality, simple operation, and network capabilities, this projector will deliver seamless presentations. Its ability to accept a broad array of signals, including those from sources equipped with the latest High-Definition Multimedia Interface (HDMI) further increases the dynamics of the presentation. This projector can be purchased with or without lenses.

Network Capability
Connected to a LAN (Local Area Network) via RJ45, the projector can be individually managed and monitored remotely via the built-in projector browser.

Optional Lenses
The VPL-FX41 projector is supplied with a motorised lens that is suitable for most general applications. If a specific application requires a special lens, then the lens-less VPL-FX41L model is available.

Other Features
­ Flexible Installation ­ Direct Power On ­ Easy Maintenance ­ Monitor Out ­ Dynamic Digital Enhancer

High Picture Quality
The VPL-FX41 incorporates 12-Bit 3D Gamma Correction Circuitry to perform highly accurate gamma correction, achieving uniform image colour and brightness that extends right to the corners of the screen.

Multi-input
The VPL-FX41 accepts a wide range of input signals including HDMI, component and composite video, S-Video (Y/C), and computer signals up to UXGA (fV: 60Hz).

VPL-FX41(L) Specifications
Key Specifications Native Resolution Max Signal Input Resolution Panel Type Projection System Brightness Contrast Ratio Fan Noise Weight Dimensions (W x H x D) General Standard Lens Vertical Keystone Correction Vertical and Horizontal Shift Lamp Type Lamp Life (Replacement time) Max Power Consumption Standby Power Consumption Throwing Distance (Standard Lens) Min ­ Max Screen Size (diagonally) 40-inch / 1m screen 80-inch / 2m screen 100-inch / 2.5m screen 150-inch / 3.8m screen 200-inch / 5.1m screen 300-inch / 7.6m screen 600-inch / 15.2m screen Inputs/Outputs VIDEO IN Video S Video Audio Stereo INPUT A Analogue RGB Audio INPUT B Analogue RGB Audio INPUT C Analogue RGB/ component Audio INPUT D INPUT E OUTPUT Digital RGB Network Monitor out Audio REMOTE RS-232C Control S IN Composite Video (RCA phono jack) Y/C Mini DIN 4-pin (RCA phono jack) HD D-sub 15-pin (female) Stereo mini jack HD D-sub 15-pin (female) Stereo mini jack 5BNC Stereo mini jack Digital RGB/Y CB (PB) CR (PR): HDMI (HDCP) RJ45: 100Base-TX/10Base-T Analogue RGB: HD D-sub 15pin Stereo mini jack (variable out) D-sub 9 pin (female) Stereo mini jack (plug-in-power) 40 ­ 600 inch* 1.48 ­ 1.9m 3.03 ­ 3.86m 3.81 ­ 4.84m 5.74 ­ 7.29m 7.68 ­ 9.74m 11.55 ­ 14.64m 23.16 ­ 29.35m Inputs VPLL-Z1024 Zoom Lens (2.38 ­ 3.26:1) 1.3 times powered zoom lens (1.875-2.38:1) (standard lens supplied with VPL-FX41) Max. ± 30° Vertically V Shift 0 ­ 1/2V / H Shift 1/10 H [except VPLL-1008] 275W Ultra High Pressure lamp 2000 / 3000 Hours 400W 15W (Standby mode: standard)/0.5W (low) LMP-F270 Lamp XGA (1024 x 768) Up to UXGA 1600 x 1200 0.79" TFT LCD x 3 3 Inorganic LCD panels, 1 lens system 5200 [High mode]/4160 [Standard mode] 900:1 39dB / 30dB Approx 9.8 kg (Approx 9.0 kg for VPL-FX41L) 532 x 145 x 352 mm Optional Accessories BZSQ-M001 Ziris Manage Lite Software Optional Software

www.sonybiz.net/projectors

Ziris Manage application software monitors networked playout devices, reports their status, it enables power control of displays and projectors, and switching of their inputs and provides status of other Ziris applications.

PAM-300 Ceiling Bracket

VPLL-1008** Fixed Lens (0.78:1)

VPLL-Z1032 Zoom Lens (3.24 ­ 4.95:1)

VPLL-Z1014 Zoom Lens (1.4-1.875:1)

· Halogenated flame retardants are not used in cabinets or printed wiring boards. · Corrugated cardboard is used for the packaging cushions. · Standby power consumption: 0.5 W

* For VPL-FX41L,screen coverage is 40-600 inches with Standard Lens, VPLL-Z1024, VPLL-Z1014 or VPLL-Z1032 / 60-300 inches with VPLL-1008. ** VPLL-1008 for floor installation or tilt free installation only.

All Sony business projectors come supplied with a 3-year support pack which offers unique extra services and benefits. · 3 years' cover · Free telephone helpdesk support in 5 languages · Collection and delivery anywhere in EU, Norway and Switzerland
