UPX-C100
Photo and Digital Printing System
Instant photos, instant revenue. Enabling you to enter today's passport ID photo market with minimal investment, the UPX-C100 is a turnkey solution, allowing you to start a profitable passport ID business from the moment it is installed.
Two in One Consisting of a high quality 5 megapixel digital still camera and photo printer, the system couldn't be simpler to operate. Both the camera and printer (connected via a USB cable) are packed with sophisticated, yet easy to use functions and provide a truly simple and effective way to get started in the lucrative passport ID photo business. Professional photography, made easy The UPX-C100 is very simple to operate, right from set-up and taking pictures, to printing them out. All functions, including image size adjustments can be operated directly from the camera itself. There are just three simple steps from image capture to print; Click the shutter button Review the image on the camera's LCD screen Press the Print button What could be a simpler way to get professional digital prints? As simple or as advanced as you like It really can be as easy as "point and click" to get photo-quality digital prints. The UPX-C100 does have, in addition, advanced features which enable you to get more out of the system.
Click the shutter button
Review the image on the camera's LCD screen
Push print button
Photo is printed in arround 65 seconds
Take another photo in around 19 seconds
Auto Review
Auto Review The Auto Review function automatically displays the captured image on the LCD screen after the shutter button is pressed, allowing you and your customer to check the photo before printing it  and it stays on screen until the next photo is taken. Perfectly-sized images There are four preset frame sizes to choose from, while customised frames can also easily be created. These advanced alignment tools mean that you get the exact size image you need every time, quickly and easily. The system also supports the new standard passport photo regulations. Easy colour adjustment The built-in colour-guide function makes it easy to adjust hue, contrast and tone in order to further enhance image quality. Versatile printing Three different print packs are available allowing you to meet all types of passport and ID photo requirements. These packs allow you to create various types of print out, including a combination of different sizes on one sheet.
Colour and B/W printing The UPX-C100 provides both colour and black and white print options, for a variety of Passport and ID photo requirements. USB connectivity The UPX-C100 is equipped with a USB interface, enabling images to be transferred quickly from the camera to the printer. Compact, space-saving design Both the camera and the printer have compact designs, enabling them to fit into the smallest of spaces. Language support The UPX-C100 features a choice of 12 languages on the camera menus including English, French, Spanish, German, Italian, Portuguese, Dutch, Russian and Arabic.
Digital Photo Printer USB connection
Specifications Optional Accessories
Digital still camera image device · picture elements · 1/2.5 inch CCD with 5M pixels (effective) 2576 x 1932 pixels (FULL) 1280 x 960 pixels (HIGH) 832 x 624 pixels (STD) 1280 x 960 pixels (HIGH-ID) 832 x 624 pixels (STD-ID) built-in 16 MB flash memory JPEG Exif 2.2 compliance Full: approx. 10 images High: approx. 40 images STD: approx. 73 images High-ID: approx. 40 images STD-ID: approx. 73 images auto, onepush, 3000 K to 7000 K (500 K steps) F2.8/F5.6 selectable (Wide), F4.8/F9.6 selectable (TELE) -2 to ±2 (1/3 steps) selectable f=5.7 to 17.1 mm (1/4 to 11/16 inches), 3 times auto, manual 1/2 to 1/1000 seconds auto focus (0.8 m and over) internal flash (GN6) equivalent to ISO 100 2.0-inch TFT color LCD (110K pixels) USB host port for the printer DC In (5.0 V) or AA batteries (2) 97 (W) x 64(H) x 32 (D) mm (3 7/8 x 2 5/8 x 1 5/16 inches) approx. 134 g (4.73 oz) (without batteries)
4 3 2 1
recording media · data compression · image format · memory capacity ·
white balance · iris · manual exposure · lens · shutter speed · focus · flash · sensitivity · LCD monitor · interface · power supply · dimensions · mass ·
Digital photo printer printing method · resolution · gradations · maximun print size · Dye Sublimation thermal transfer 403 dpi 8 bits for yellow, magenta, and cyan UPC-X34: 70.1 x 95.3 mm (2 7/8 x 3 7/8 inches) (with border) UPC-X45: 97.8 x 120.0 mm (3 7/8 x 4 3/4 inches) (with border) UPC-X46: 101.6 x 151.4 mm (4 x 6 inches) (no border) UPC-X34: approx. 65 seconds UPC-X45: approx. 90 seconds UPC-X46: approx. 100 seconds UPC-X34: 30 sheets UPC-X45: 25 sheets UPC-X46: 25 sheets
3 1
10UPC-X34 Self-Laminating Colour Printing Pack Contents: 30 sheets x 10 packs (300 sheets) Paper size: 90 x 101.6 mm (3.5 x 4 inches) 10UPC-X46 Self-Laminating Colour Printing Pack Contents: 25 sheets x 10 packs (250 sheets) Paper size: 101.6 x 152.4 mm (4 x 6 inches)* * The measurement between the two perforated lines. 10UPC-X45 Self-Laminating Colour Printing Pack (Water ink stamp capable) Contents: 25 sheets x 10 packs (250 sheets) Paper size: 101.6 x 141 mm (4 x 5 5/8 inches) UPA-DX100TR Paper Tray (for 10UPC-X45)
2
printing time ·
paper tray capacity ·
interface · power requirements · dimensions · mass ·
USB AC 100 to 240 V, 50/60 Hz Approx. 203 (W) x 85 (H) x 305 (D) mm (8 x 3 3/8 x 12 1/8 inches) Approx. 2.7 kg (5 lb 15 oz)
4
General
