SNC-CH180
Network HD Bullet Camera --- V Series
High-Quality 720p HD Security Camera with IR Illuminator and View-DR
Excellent 720p HD picture quality, supporting H.264 at 30 fps 1.3 Megapixel (1280 x 1024) maximum resolution Three codecs (H.264, MPEG-4, JPEG) and a dual streaming capability The "Exmor" CMOS sensor incorporated to realize high image quality and low noise
Key Features
· View-DR--Sony's innovative Wide Dynamic Range technology--to capture objects clearly and adaptively even under very harsh severe backlight or highlight conditions.
· Optical Day/Night function to switch to Day or Night mode depending on the light level. · XDNR (eXcellent Dynamic Noise Reduction) technology for clear images without motion blur under low illumination.
OFF
ON
Actual Images
OFF
· Visibility Enhancer to optimize the brightness and color reproduction of an image dynamically on a pixel-by-pixel basis while continuously adapting to the scene, within the given dynamic range. · Built-in IR (Infrared) illuminators to assist capturing objects in the dark even under 0 lx, up to 15 m (49 feet) away.
ON
Actual Images
· Powered by either AC 24V, DC 12V, or PoE (Power over Eithernet) for easy installation. · Equipped with a built-in heater for continued camera operation in cold whether supported (Â30°C to +50°C). OFF ON Actual Images · Equipped with a BNC connector and a phono jack to instantly monitor the video while installing the camera. · ONVIF (Open Network Video Interface Forum) conformance that ensures greater interoperability and more flexibility in building multiple-vendor systems.
· IP66-rated waterproof and dust-tight feature for outdoor surveillance, or indoor where water ingress may pose an issue. · Easy Focus/Easy Zoom functions for easy installation. · DEPA Advanced Intelligent Video and Audio Analytics to trigger an alarm, based on user-defined rules. · Equipped with CF slot for on-board recording and wireless operation capability with the optional SNCA-CFW5 802.11g card.
SPECIFICATIONS
SNC-CH180
Camera Image device Minimum illumination Number of effective pixels (H x V) Electronic shutter speed Gain control Exposure control White balance mode Lens type Zoom ratio Horizontal viewing angle Focal length F-number Minimum objects distance Powered focus Powered zoom IR illuminators Camera Features Day/Night *3 Wide-D Image enhancement Noise reduction Image Codec image size (H x V) Video compression format Codec streaming capability Maximum frame rate Audio Audio compression Scene Analytics Intelligent motion detection Intelligent object detection Rule filter Network Protocols ONVIF conformance Wireless network Number of clients Authentication Analog Video Output Signal system Horizontal resolution S/N ratio Interface Ethernet Serial interface Card slots Analog video output Analog monitor output Sensor input Alarm output External microphone input Audio line output General Mass Dimensions Power requirements Power consumption Starting temperature Working temperature Storage temperature Ingress protection Safety Regulation System Requirements Operating system Processor Memory Web browser Supplied Accessories 1/3 type progressive scan "Exmor" CMOS sensor Color: 0.22 lx, B/W: 0 lx - IR ON (F1.2/View-DR OFF/XDNR ON-Middle/VE OFF/AGC High/50 IRE [IP]) 1.4 Megapixel (1329 x 1049) 1s to 1/10000s Auto (3 levels) Auto, EV Compensation *1, Auto Slow Shutter *2 Auto (ATW, ATW-PRO), Preset, One-push WB, Manual Vari-focal lens Optical 2.9X (x2 Digital Zoom) 85.4 to 31.2 degrees f=3.1 to 8.9mm F1.2 (Wide), F2.1 (Tele) 300 mm Yes (Easy Focus) Yes (Easy Zoom) Yes (Wave Length: 850nm [Typical], IR LED: 27pcs) Yes View-DR (125dB: Theoretical) Visibility Enhancer XDNR 1280 x 1024, 1280 x 960, 1280 x 800, 1280 x 720, 1024 x 768, 1024 x 576, 800 x 480, 768 x 576, 720 x 576, 720 x 480, 704 x 576, 640 x 480, 640 x 368, 384 x 288, 320 x 240, 320 x 192 (H.264, MPEG-4, JPEG) H.264, MPEG-4, JPEG Dual streaming H.264: 20fps (1280 x 1024) / 30 fps (1280 x 720) MPEG-4: 25fps (1280 x 1024) / 30 fps (1280 x 720) JPEG: 30fps (1280 x 1024) / 30 fps (1280 x 720) G.711/G.726 Yes (with built-in Post Filter) No Yes IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) Yes Yes (with Option *4) 10 IEEE802.1X NTSC / PAL 600 TV lines More than 50dB 10BASE-T / 100BASE-TX (RJ-45) No CF card x1 BNC x 1 Phono jack x 1 x1 x2 Mini-jack (Monaural), MIC IN/LINE IN: 2.5VDC plug-in power Mini-jack (Monaural), Max output level: 1 Vrms 1650 g (3 lb 10 oz) ø 93 x 186 mm (3 3/4 x 7 3/8 inches) PoE *5, AC24V, DC12V 30 W Max. AC24V/DC12V: -20 to +50 °C (-4 to +122°F) PoE (IEEE802.3af): 0 to 50 °C (32 to 122°F) AC24V/DC12V: -30 to +50 °C (-22 to +122°F) PoE (IEEE802.3af): -10 to +50 °C (23 to 122°F) -20 to +60 °C (-4 to +140°F) IP66 UL2044, FCC 15B Class A, IC Class A, IEC60950-1, EN55022(A)+EN55024+EN50130-4, VCCI Class A, C-Tick Class A Windows XP, Windows Vista, Windows 7 Intel Core2 Duo 2 GHz or higher 1 GB or more Microsoft Internet Explorer Ver6.0, 7.0, or 8.0 CD-ROM (User's Guide, SNC Toolbox) Installation manual Wire rope M4 screw B&P Warranty Booklet Template
*1 VE off mode only. *2 View-DR off mode only. *3 Removable IR Cut Filter. *4 With optional SNCA-CFW5. *5 When used with PoE, SNC-CH180 cannot be used with a heater and a CF card slot. The SNC-CH180 includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/).
SYSTEM CONFIGURATION
CF Wireless Card HD monitor SNCA-CFW5 (IEEE802.11g)
SNC-CH180
Wireless Access Point
Recording Server NSR-1000 Series Recording Software IMZ-NS100 Series
Network
SNC-CH180
PC
DIMENSIONS
R10 0 (4 )
