TUNER METRONOME
MU40
OWNER S MANUAL
Caution
%Ï To avoid short circuit, electric shock or malfunction:
Do not disassemble for repair.
Do not place in high temperature and humid space such as electric heater, direct sunlight, bathroom, wet floor etc.
Do not place in excessive vibration.
Do not place in dusty or dirty space.
Do not operate the tuner with wet hands.
%Ï To avoid breakdown
Do not handle all controls with excessive power.
Do not drop the tuner.
%Ï Cleaning
Do not use thinner or alcohol for cleaning.
Use only dry and clean cloth.
%Ï To prevent battery loss
Remove the battery when the tuner is not in use for a long time.
Turn the power button off when the tuner is not in use.
%Ï Battery
Use only 3V battery : AAA Size (R03, LR03, L30) ' 2
Functions and Features
By using the built-in mic you can also tune an acoustic guitar or similar instrument.
If the pitch of your instrument is more than 50 cents away from the correct pitch, tune your instrument until the correct note name appears in the LCD and one or the other guideline LED is lit.
If the pitch is within 50 cents of the correct pitch, watch the needle of the meter and tune your instrument so that the needle is at the 0 position.
When the tuner needle stops at 0 the center LED will light; your instrument is tuned correctly.
%Ï Using SOUND mode while you tune
When you press the SOUND button, the NOTE will indicate A and the A pitch will sound. As necessary, use the FUNCTION button and the buttons to change the
NOTE and/or FLAT settings to the desired note, and tune your instrument.
[METRONOME]
Press the POWER ON/OFF button to turn the power on.
Press the TUNER/METRONOME button to enter METRONOME mode.
In this mode the MU40 functions as a metronome. You can use the FUNCTION button and buttons to change the BEAT, TEMPO, TAP, and RHYTHM settings.
