XC-505 XC-505P
Colour Video Camera
IMAGE SENSING SOLUTIONS

The XC-505 and XC-505P are ultra-compact and lightweight colour video cameras incorporating a high-sensitivity, high-performance 1/3-type Super HAD II CCD.

XC-505

XC-505P

Features

High-sensitivity Super HAD II CCD

Compared to Sony's popular XC-555 camera, the XC-505 and XC-505P are equipped with several new features including one-push white balance, noise reduction (2D/3D), a built-in colour bar, DTL function, and RS-232C support.
These cameras use an NF lens system which can easily be converted into a flexible C-mount lens. What's more, they are simply integrated into space-restricted environments thanks to their one-piece compact and robust body. The combination of first-class picture quality with superb sensitivity for less-than-ideal lighting conditions makes these cameras ideal for a wide range of applications such as remote monitoring, security, content creation, machine vision, and sports shooting.

One-piece body and amazingly compact design 22 (H) x 22 (W) x 64 (D) mm, 51 g (7/8 x 7/8 x 2 5/8 inches, 2 oz) Selectable video outputs and external synch inputs ­ Video outputs: VBS and Y/C ­ External synch: HD/VD, VS, VBS (no genlock) Easy camera setting by dip switch or RS-232C serial communication Various image acquisition features: ­ Selectable Auto Exposure and White Balance ­ Defective pixels correction ­ 2D/3D Noise Reduction (NR) ­ Edge Enhancement/Detail Enhancement ­ E-flip ­ Built-in colour bar

www.pro.sony.eu/vision

Specifications

XC-505 Image sensor Colour filter Effective picture elements (H) x (V) Scanning system Lens mount Sync system Horizontal resolution Minimum illumination Sensitivity S/N ratio 470 TV lines 1.5 lx at F1.4 AGC: max (18 dB) 2000 lx at F11 AGC: OFF (0 dB) 48 dB (standard) AGC: OFF (0 dB) Super HAD II 1/3-type IT CCD Complementary colour mosaic 768 x 494 pixels 525 lines, 2:1 interlace, 30 frames/sec NF mount

XC-505P

752 x 582 pixels 625 lines, 2:1 interlace, 25 frames/sec

Internal/External (automatic switching) 460 TV lines

46 dB (standard) AGC: OFF (0 dB) 1/50 sec (OFF) (PAL), 1/1000 sec, CCD IRIS, and FLICKERLESS (selectable)

1/60 sec (OFF) (NTSC), 1/1000 sec, CCD Shutter speed IRIS, and FLICKERLESS (selectable) White balance Gain control

3200K, 5600K, One Push WB, ATW (auto tracing white balance), and MAN (manual) (selectable) AGC/Fixed (0 dB) VBS/Y/C (selected with the switch) VBS: 1 Vp-p, 75 ohms, sync negative Y: 1 Vp-p, 75 ohms C: C level depends on the composite video out signal HD/VD, VS, VBS (no genlock) DC IN/SYNC/VIDEO: multi 12-pin 0°C to 40°C (32°F to 104°F) -30°C to +60°C (-22°F to +140°F) 20% to 80% (no condensation permissible) 20% to 90% (no condensation permissible) DC 10.5 V to 15 V 1.5 W 10 G (20 Hz to 200 Hz) 70 G 22 x 22 x 64 mm (7/8 x 7/8 x 2 5/8 inches) 51 g (2 oz.) Lens mount cap (1), Tripod adaptor (1 set), Operating instructions (1)

Video output

External synchronous input Output connect Operating temperature Storage temperature Operating humidity Storage humidity Power requirement Power consumption Vibration resistance Shock resistance Dimensions (W x H x D) Mass Supplied Accessories

Dip switches for setting functions

DC IN/VIDEO connector (multi 12-pin)
Signal Sync signal types External Sync signal
3 1 9 2 10 8 7 11 12 6 5

Pin No. 1 2 3 4 5 6 7 8 9 10 11 12

HD,VD GND +12 V VBS/Y Output (GND) VBS/Y Output (signal) HD Input (GND) HD Input (signal) VD Input (signal) GND (-/C) -/C Output (signal) RS-232C (TXD) * RS-232C (RXD) * VD Input (GND)
