INSTRUCTION FOR USE
BEFORE USING THE GLASS CERAMIC
HOB
INSTALLATION
ELECTRICAL CONNECTIONS
ENERGY SAVING TIPS
SAFEGUARDING THE ENVIRONMENT
PRECAUTIONS AND GENERAL
RECOMMENDATIONS
HOB ACCESSORIES
CARE AND MAINTENANCE OF THE
GLASS-CERAMIC HOB
TROUBLESHOOTING GUIDE
AFTER SALES SERVICE
81
BEFORE USING THE GLASS CERAMIC HOB
" To make the most of your new appliance,
please read the user instructions carefully and keep them handy for future consultation.
INSTALLATION
Cooktop
" The cooktop must be set into a worktop between 20
mm and 50 mm deep
" There must be nothing between the cooktop and the oven (cross rails, brackets, etc.).
" The distance between the lower face of the glass ceramic hob and the cupboard or separating panel must be at least 20 mm.
" If the cooktop is to be installed next to a column unit,
leave a distance of at least 100 mm from the edge of the cooktop to the side of the column unit.
" Make an opening in the worktop, respecting the dimensions indicated in the enclosed product description sheet.
" Apply the supplied gasket to the cooktop (unless it has already been fitted), after having cleaned its surface.
Important
In order to prevent the electronic circuits from overheating, and therefore from being damaged, we recommend the following:
" Do not install the cooktop near a dishwasher or washing machine, so that the electronic circuits do not come into contact with steam or moisture, which could damage them.
If an oven (from our range of ovens) is installed beneath the cooktop, make sure that it is equipped with a cooling system.
If the temperature of the electronic circuits exceeds the maximum permitted temperature, the cooktop will switch off
