New KYOCERA 7129 Series Board to Board Connector Helps Reduce
Charging Times for Mobile Devices
Space-saving connector handles current up to 10A for smartphones, tablets, &
wearables.
Kyoto, Japan / Neuss, Germany, January 25, 2017. Kyocera Connector Products Corporation announced that it has developed a board to board battery connector for use with portable electronic devices such as smartphones, tablets and wearables. The new 7129 Series connector goes on sale January 30.
The ever-expanding functionality of today's mobile devices is creating demand for faster charging times and increased battery capacity. This requires strong, durable connectors with higher current capability. However, with board space at a greater premium than ever, connectors must meet these higher strength and current requirements within an even smaller, thinner form factor.
Kyocera's new 7129 Series board to board connector is rated for currents up to 10A to help reduce charging times for mobile devices. Additionally, despite its space-saving size just 0.7mm stacking height, 2.2mm width and 5.64mm length this robust connector is designed for high
Information presse retention, with a metal guide component to prevent mating misalignment damage to insulators and contacts.
This connector continues Kyocera's tradition of helping customers meet the latest demands of the electronic device market.
Main Features
1. 10A Current Rating
Capable of conducting up to 10 amperes of current one of the highest for smartphones*
to help reduce charging times. (Please refer to the catalog for pattern layout on PCBs .)
*
Based on research by Kyocera Connector Products as of January 2017.
2. High Retention and Mating Misalignment Protection
A metal cover enhances retention strength, which may otherwise be compromised in spacesaving connectors with low profile heights. The structure of the metal cover also helps guide connectors over a smooth surface for easy mating, and prevents damage from contact misalignment.
3. Space Savings
Compact form factor features a 0.7mm stacking height, 2.2mm width and 5.64mm length.
4. Packaged in Tape and Reel (15,000 pieces/reel)
5. RoHS compliant and Halogen-Free
6. Specifications
No. of Pins
Signal: 2 pos.
Power: 4 pos.
Rated Current (Signal)
Rated Current (Power)
DC 0.4A/Contact
